Ideal for large-scale projects requiring top-tier protection and durability.
Fabtile Roofing Membrane Ultra Pro
Ask a question
Share
Couldn't load pickup availability
Usage
Best For
High-end residential projects and large commercial buildings.
Roofs with complex designs needing maximum protection.
Fabtile Ultra Pro offers unparalleled tear resistance and durability with its three-layer construction. Designed for projects requiring the highest level of protection, this membrane delivers exceptional performance under the most demanding conditions. Its superior tear resistance, combined with high vapour permeability and waterproofing, makes it ideal for large commercial projects and high-end residential roofing that demands longevity and resilience against extreme environmental stress.
Process Overview
Roof membranes are produced through a specialized laminated nonwoven process. Initially, spunbond polypropylene is created using the traditional spunbond method. This is followed by a lamination process, where a breathable film, made from either Polyethylene (PE) or Thermoplastic Polyurethane (TPU), is sandwiched between layers of nonwoven fabric. This unique structure provides both waterproofing and breathability, making it ideal for roofing applications.
Machines Used
- Spunbond Extrusion Machines: Create the nonwoven polypropylene layers.
- Lamination Machines: Bond the breathable film between the fabric layers.
- UV-Treatment and Heat-Sealing Systems: Ensure durability and waterproofing.
Technical Specifications
- GSM: 100–200 GSM
- Water Vapor Transmission Rate (WVTR): 1000–1200 g/m²/day
- Tensile Strength: 7–15 MPa (in machine and cross direction)
Applications
Installation Guide
Begin the installation from the eaves and work upwards.
Overlap each layer by 150 mm, sealing all seams carefully.
Use premium-grade fasteners and ensure all joints are sealed with double tape.
For any assistance or queries, contact our customer support
Installation Instruction
- Ensure that all materials are pre-measured for an efficient installation process.
General Preparation
- Roof surfaces should be clear, and all battens checked for stability before installation.
Pro Tips
For extreme weather areas, ensure an additional overlap to protect against wind-driven rain.
Use high-end sealants for a completely waterproof system that will last decades
